CONTROL PANEL

Control Panel

Mainly used for housing of various kinds of relays like Auxiliary relay and protection relays.
We provide complete engineered panel from your single line diagram to the complete solution.
We supply the relay interlocking hardwired console with time delay circuits.

CONTROL DESK

Console Desk

Construction: Welded, Alcosy, 8 Fold, 5 Fold also with wooden Top MOC: CRCA MS, SS, AI members.
Application: Used as Computer console or in control room or used as mounting of counter & indication equipment.

MCC PANEL

MCC

Standard height of Draw-out MCC is 2400mm including base frame. The maximum operating height is 1800mm.
For Single front – 2400(H) X 850(W) X 600(D)mm
For Double front – 2400(H) X 850(W) X 1000(D)mm

MOSAIC PANEL

Mosaic Control Desk

Mosaic Panel is the most user friendly, reliable and economical approach to process visualization. It is suitable for all kinds of control and monitoring indicator board, for process control, power networks, & security etc. Subklew Mosaic System finds its application world wide for all types of industrial and communication network systems

HT PANEL

46

HT Panels are generally used for controlling high voltage side of any instrument or at substation. We have made following rating panels:
1. 11KV VCB indoor panel/ outdoor kiosk
2. Current Rating 630/1250/1600/2000 AMP
Rupturing Capacity: 20/25/31.5/40 KA

PURGE PANEL

Purge Panel

Purge Panel/ enclosures are designed and developed for safe use of electrical products in highly explosive areas.
Features: Purging is done as per NFPA-496. 3 Types: Purging Enclosures, Explosion Proof Enclosures & Normal Enclosures.

Junction Boxes

Mosaic Control Desk

JB’s are designed to electrical & electronics control instruments and components in indoor or outdoor areas where dust, water, oil etc. contamination are present.Apart from CRCA and SS Enclosure,Galvanized Iron enclosures,Aluminum Die cast and FRP Enclosures also available Ingress protection up to IP-67.Suitable for 110 degree door opening.

LVS

46

Display Wall, is made of Rear Projection Modular cubes,that can be organised in array,with any size and same depth. Depending on the request, there is different size & different resolutions available .Projection engines could be :CRT,LCD or DLP. It can run 24 x 7 applications and higher resolutions can be achieved by cascading of cubes.

LIE/LIR

Purge Panel

The enclosures are provided for mounting Transmitters and located in Boiler area. Transmitter racks is provided for mounting transmitters and other accessories in buildings and closed areas like the power house building / turbine hall.The grouping of exact instrument in LIE/LIR depends on the site condition / availability of process connection.

About Us

All most 38 years of experience we have expanded to match global vision & progressed steadily through up gradation of technology, quality and skills. Today, we are one of the India’s leading manufacturers of automation & control equipment.

Pyrotech has an exceptional multi-disciplinary array of products – Panels, Enclosures, LVS, LIR/LIE, Computer Consoles, Electronic products and Office-Industrial furniture. To reap advantages of Global Integrated Chain, we collaborated with companies like Synelec (LVS), Subklew (Mosaic Tile System), & Weigel Meters (Meters). In every true sense of the word, we have become,
“The Control Room Solutions Provider.”
Approved by major consultants and working with large OEMs, we are in position to cater to the needs of a Variety of industries, ranging from Power to Petrochemicals, Metering to Railways, Material Handling to Process Control, Cement to Defense and many more.
